Hong Kong Dragon Fist Trade Services Limited is one of the leading suppliers and exporters of flatbed tow truck in China. With access to China's automotive supply chain, we help buyers find suitable vehicles and manage the export process from China to their markets. Welcome to wholesale bulk premium Chinese cars at competitive price from China!
This Flatbed Tow Truck is a professional road rescue vehicle complying with Euro VI emission standards. Its structural parts are made of Q700 high-tensile steel, with full-body electrophoretic coating for superior anti-rust performance. The flatbed surface features anti-slip hole design to prevent slipping during vehicle loading. It offers multiple power choices with steady power output and a top speed of 105km/h, suitable for long-distance rescue transportation.
We provide three optional superstructure types: slope plate, remote-control integrated tilting plate and full-landing plate, and heavy-duty versions are available for all options. The flatbed can be fully laid flat for easy loading of low-chassis vehicles. It comes with long steel wire rope and long slide travel, helping operators recover accident or broken-down vehicles efficiently. Different spring tower setups can be customized to match various towing demands, making it a dependable workhorse for roadside assistance, auto recovery and highway clearance business.
Flatbed Tow Truck Main Paremeter
| Item | Parameter | Item | Parameter |
|---|---|---|---|
| Product Name | Flatbed Tow Truck | Overall Dimensions (mm) | 59952550,2450,23802280,2250,2230 |
| Product Model | DF-5041TQZF6A | Approach/Departure Angle (°) | 22/16 |
| Chassis Model | BJ1045V9JDA-AB1 | Front/Rear Overhang (mm) | 1120/1515,1275 |
| Gross Vehicle Weight (kg) | 4495 | Max Speed (km/h) | 105 |
| Rated Load (kg) | 1500 | Number of Axles | 2 |
| Curb Weight (kg) | 2800/2865 | Wheelbase (mm) | 3360/3600 |
| Axle Load (kg) | 1575/2920 | Front/Rear Track (mm) | 1590/1800 |
| Tire Specification | 7.00R16LT 8PR | Cab Seating Capacity | 2, 3 |
| Bed Outer Length/Inner Length (mm) | 4185*4145 | Bed Outer/Inner Width (mm) | 2380*2340 |
| Min. Bed Loading Angle (°) | 5.5/4 | Slide Stroke (mm) | 3400 |
| Rear Flap Height (mm) | 1050 | Full Bed Length (mm) | 5340 |
| Steel Wire Rope Length (m) | 24 | Optional Upper Structures | Slope plate, remote-controlled tilt-and-landing integrated plate, full-landing plate (remote control optional); heavy-duty version available for all three |
| Engine Manufacturer | Kunming Yunnei / Beiqi Foton | Emission Standard | GB17691-2018 National VI |
| Engine Model | YN25PLUS10 / YN25AL / 4F25TC | Displacement | 2499ml |
| Power/Horsepower | 111kW(150hp),107kW(145hp),116kW(158hp) | Materials | Full-body electrophoretic coating, anti-slip punched flatbed surface, Q700 high-strength steel structural parts |
